The cable pusher version has been designed to allow cable to be lifted in from one side. Cable Laying Equipment design has the advantage of being more

The cable pusher version has been designed to allow cable to be lifted in from one side. Cable Laying Equipment design has the advantage of being more compact when used in restricted areas such as a trench. Cable laying machines is easier to lift heavy cable into the side of the pusher than cable pusher is to lift it over the pusher and into the top. The hydraulic power Cable Laying Equipment unit includes the control laying and is positioned remotely, generally on the embankment above the trench.

Specification cable pusher

HYDRAULIC POWERPACK
Diesel Engine	Kubota D902 - 15 kW @ 3600 rpm
Fuel Tank Capacity	40 L
Engine Oil	Shell Rimula
Hydraulic Oil	Castrol Hyspin AWH 46
Hydraulic Fluid Reservoir Capacity	90 Litres
Run time/tank	8 -9 hrs dependant on workload
Hydraulic Load Sense Piston Pump	25 L/min
Maximum System Pressure	240 bar (3500 psi)
Hydraulic Power unit Mass	482 kg
CABLE PUSHER
Frame Footprint	Fits into 730 mm trench Refer to attached drawing
Cable Pusher Unit Overall Dimensions (LxWxH)	1350 mm x 900 mm x 534 mm
Push or Pull	Machine is capable of pushing, pulling or pushing and pulling.
Clamping pressure	User adjustable. Clamping pressure and pull/push force displayed on gauges.
Maximum Cable Push Force (at reduced line speed)	20kN (2000kg)
Maximum Line Speed (at reduced push force)	25 m/min
Line cable speed and distance display	On pendant
Capstan Pull	Capstan enables polypropylene rope to be winched
Maximum Capstan Winch Line Pull Force	16 kN (1600 kg)
Maximum Capstan Winch Line Pull Speed	23 m/min
Adjustable Jaws, Cable Capacity.	50 to 140 mm cables
Pusher Unit Overall Dimensions (LxWxH)	1350 mm x 900 mm x 534 mm
Cable Pusher Mass	420 kg

Cable Laying Equipment not only applied for traction power cable, communication cable and aerial wire, also for other tranction fields in the situation of cable duct, tunnel, direct-burried, long-distance transmisson. Cable laying machines has small volume light weight, strong thrust force ,easy to operate, so cable pusher can be used alone or coordinated with our company other conveying sets.
